Balances · Analytical balances
JOANLAB dual-range analytical balance · CEB series
CEB1035 · 120 g and 31 gCEB1055 · 120 g and 51 gCEB1085 · 120 g and 81 gCEB2035 · 220 g and 31 gCEB2055 · 220 g and 51 gCEB2085 · 220 g and 81 gCEB1035N · 120 g and 31 g · internal calibrationCEB1055N · 120 g and 51 g · internal calibrationCEB1085N · 120 g and 81 g · internal calibrationCEB2035N · 220 g and 31 g · internal calibrationCEB2055N · 220 g and 51 g · internal calibrationCEB2085N · 220 g and 81 g · internal calibration
Analytical balances with two weighing ranges switchable on the same unit, standard RS232 and USB, and internal calibration in the N series.
- Two independent programs: 0.1 mg and 0.01 mg
- Capacity of 120 or 220 g depending on the model
- Bidirectional RS232 and USB, with export to Excel
- Internal calibration with dynamic compensation in the N series
Configurations, certifications, power supply, accessories and availability are confirmed in the quote.
Specifications
Summary datasheet
| Weighing ranges | 120 g/31 g, 120 g/51 g, 120 g/81 g, 220 g/31 g, 220 g/51 g and 220 g/81 g depending on the model |
| Readability | 0.1 mg in the wide range; 0.01 mg in the fine range |
| Stated repeatability | 0.1 mg in the wide range; 0.03 mg in the fine range |
| Linearity error | 0.2 mg in the wide range; 0.03 mg in the fine range |
| Stabilization time | About 2 s in the wide range and 3 s in the fine range |
| Preheating time | 30-60 min |
| Calibration | External in the CEB series; automatic internal in the CEB…N series |
| Pan | Ø90 mm |
| Interface | RS232 and USB standard |
| Weighing units | Gram, ounce, carat and milligram, plus a user-definable unit |
| Dimensions | 220 × 403 × 310 mm |
| Power supply | Configuration to be confirmed for Chile |
| Shipping package | 49 × 38 × 48.5 cm and 10 kg |
| Availability | Imported to order / to be confirmed |
Two ranges in a single body
The full range (120 or 220 g depending on the model) reads at 0.1 mg with ±0.1 mg repeatability; the fine range (up to 31 or 51 g) goes down to 0.01 mg at ±0.03 mg. That is the family's idea: the small sample is weighed ten times finer without changing instruments.
The stated linearity error is ±0.2 mg on the full range and ±0.03 mg on the fine one, with stabilization of 2 to 3 seconds depending on the range.
The N calibrates itself, and the outputs come fitted
The N versions carry internal calibration and the standard ones external; RS232 and USB are standard across the family, with a Ø90 mm pan and g, oz, ct, mg and custom units.
